Characteristics of optical fiber welding machine

Optical fiber splicing machine is a kind of equipment specially used for optical fiber connection, and its main characteristics can be summarized as follows:

First, high precision

Core Alignment technology: The optical and mechanical technologies, such as the Passive Alignment System (PAS) core alignment technology, are used to ensure that the core of two optical fibers can be accurately aligned during welding, thus achieving high-precision fiber connection. This alignment method can significantly improve the welding quality and reduce the connection loss.

Magnification and clarity: Some high-end fiber splices are equipped with high-resolution displays that can magnify the fiber image to hundreds of times (such as 250 or 300 times), making the core clearly visible for operators to accurately observe and adjust the position of the fiber.

Second, high efficiency

Rapid welding and heating: Modern optical fiber welding machines usually have a short welding time and heating time, such as 8 seconds rapid welding and 30 seconds heating, which greatly improves work efficiency. In addition, some welding machines also have automatic control functions, which can automatically complete a series of welding steps, reducing manual intervention.

Large-capacity battery and endurance: In order to meet the needs of households for long working hours, optical fiber welding machines are often equipped with large-capacity lithium batteries, which support welding while charging, and can be welded and heated multiple times after full charge, ensuring the continuous working ability of the equipment.

Third, safe and reliable

Windproof and dustproof design: Considering the complexity of outdoor work, optical fiber welding machines usually adopt windproof and dustproof design, such as fluted windproof cover and shock-proof structure, to ensure that they can still work stably in harsh environments.

Self-test and diagnosis function: Some high-end welding machines have system self-test function, which can monitor equipment status in real time and diagnose potential faults to ensure that the welding machine is in the best working condition at any time. At the same time, these devices can automatically identify different types of fiber and set corresponding welding parameters.

Fourth, portability and humanized design

Compact and lightweight: The optical fiber welding machine is small in size, light in weight, easy to carry and operate. This allows engineers to perform optical fiber welding work more flexibly during field construction.

Humanized operation interface: In order to facilitate the use of operators, optical fiber splicing machines are usually equipped with humanized operation interface and intelligent menu design. These designs make the operation of the equipment more intuitive and easy to understand, lowering the barrier to use.

Fifth, wide applicability

Multiple fiber type support: The fiber splicing machine can support multiple types of fiber splicing, including single mode (SM), multi-mode (MM), dispersion shift (DS) and non-zero dispersion shift (NZDS) fiber types. This allows the device to play an important role in different fields and application scenarios.

Plateau and low temperature environment adaptability: Some high-end optical fiber welders can work stably at high altitudes (such as 5000 meters) and low temperatures, ensuring the wide coverage and reliability of optical fiber communication networks.

To sum up, optical fiber splicing machine plays an irreplaceable role in the field of optical fiber communication with its characteristics of high precision, high efficiency, safety and reliability, portability and wide applicability.
