30mm Micro Fiber Heat Shrink Sleeves 250μm Bare Fiber Splice Protectors

30mm Micro Fiber Heat Shrink Sleeves 250μm Bare Fiber Splice Protectors

Description:

 Fiber Optic Heat Shrinkable Sleeves is used to protect the optical fusion fiber. The construction of the three protective and strengthening elements of the Fiber optic Sleeve is distinctive in the function that each provides. The inner stainless steel pin keeps the sleeve rigid and stable. The pin is vibratory tumbled with a special medium. This eliminates the possibility of fiber scarring or material penetration, both of which could damage the sensitive glass fibers. The inner tube is made of a specially designed material that compresses. The fiber splice becomes encapsulated within the inner tube. The outer tube is made of a heat-shrinking polyolefin. This encloses the inner tube and the encapsulated fiber splice, providing double protection and ensuring that moisture and air are eliminated from the fiber splice.

 0.5mm Steel Rod 30mm Length Micro Fiber Optic Heat Shrinkable Sleeves is designed for 250μm bare fiber splicing protection. Length is 30mm only, it is special used in smaller application, such as CWDM, DWDM ect. 0.5mm Steel Rod 30mm Length Micro Fiber Optic Heat Shrinkable Sleeves is commonly known as an optical fiber heat shrink protect sleeve. 0.5mm Steel Rod 30mm Length Micro Fiber Optic Heat Shrinkable Sleeves is widely used in communication optical fiber splicing projects, it is consisted of a special cross-linked polyolefin, a hot melt tube and a strengthen member.

 We offer a number of high quality splicing sleeve options.Micro series lengths include 15mm, 20mm 25mm, 30mm 35mm and 40mm. Sleeves come standard with a clear tube for viewing the color of the fiber itself.
It is specially designed to improve the mechanical strength of the optical fiber welding point and ensure the reliability of the splicing; does not affect the optical transmission characteristics of the optical fiber; The use method is simple and safe, reducing the risk of adverse effects on optical fiber during use; The transparent sleeve can monitor the optical fiber splicing at any time; The inside is completely sealed, so that the welding point has good high temperature and high humidity resistance.

Features:

1. Provide mechanical and environmental protection for fusion splices

2. Optimal design for simple and correct fiber entrance

3. Hot melt adhesive especially developed for optimal flow

4. Transparent heat shrinkable tube for simple installation verification

5. Short installation cycle and compatible with most common ovens

6. Specially designed by the cross-linked polyolefin,hot melt tube and enhanced stainless steel wire/ ceramic/quartz optical fiber splice protection devices,does not affect the fiber optic light guide features.

7. protect splices and improve the mechanical strength.

8. simple operation, reduce the risk of damage fiber installation.
