Model Number: LC/UPC
Insertion Loss:<0.2db
Return Loss: >50db
Use: FTTH, FTTX, FTTA, CATV, lAN'S
FTTH LC Adapter with Flange LC Upc mm Om3 Quad Connector Adaptor Fiber Optic Accessories Adapter Telecom Network
Description:
Fiber optic adapters are used to provide a cable to cable or cable to equipment fiber optic connection. Chengdu Focus Infra Materials company is manufacturing a wide range of mating sleeves and hybrid adapters, including special male to female hybrid fiber optic adaptor. you're always welcomed to contact us at yuki.cdfocusinfra.com for any inquiries.
Features:
Adapters for most size connectors
Over 50 types of adapters
Bare Fiber Adapter
Standard 2.5mm adapters (ST, FC and SC)
Small size waveform: 1.25mm (LC, MTRJ, etc.)
POF type connection adapter (HFBR, Toslink, e.t.c.)
Can be used for connection of single and multi-mode connectors
Can be divided into fiber optic adapters, duplex adapters and quad adapters
Paremeters
Type | Insertion loss(db) | Tensility resist(g) | Inser and pull times | Temperature(ºC) | |
FC | PC | < 0.2 | 200-600 | 1000 | -40-+80 |
APC | < 0.2 | ||||
SC | PC | < 0.2 | 200-600 | 1000 | -40-+80 |
APC | < 0.2 | ||||
ST | < 0.2 | 200-600 | 1000 | -40-+80 | |
LC | < 0.2 | 200-600 | 1000 | -40-+80 | |
MU | < 0.2 | 200-600 | 1000 | -40-+80 | |
MIRJ | < 0.2 | 200-600 | 1000 | -40-+80 | |
E-2000 | < 0.2 | 200-600 | 1000 | -40-+80 | |
FC-SC | < 0.2 | 200-600 | 1000 | -40-+80 | |
FC-ST | < 0.3 | 200-600 | 1000 | -40-+80 | |
SC-ST | < 0.2 | 200-600 | 1000 | -40-+80 |
