2 Inlets 2 Outlets Outdoor Horizontal Type 144 Core Fiber Optical Splice Enclosure Box

Model Number : FS-J-005
Cable Port: 2 Inlets 2 Outlets
Scope Of Application: 12 Core To 144 Core
Product Size: 645*220*165mm

2 Inlets 2 Outlets Outdoor Horizontal Type 144 Core Fiber Optical Splice Enclosure Box


Description:

  2 Inlets 2 Outlets Outdoor Horizontal Type 144 Core Fiber Optical Splice Enclosure Box, also known as 2 Inlets 2 Outlets Outdoor Horizontal Type 144 Core Fiber Optical Splice Joint Box, is the place where the end of optical cable is connected. Then it is connected to optical switch through optical fiber jumper to prevent material aging caused by heat, cold, light, oxygen and microorganisms in nature. It also has excellent mechanical strength. The solid shell and main structure of optical cable junction box can endure the worst environmental changes, and play a flame retardant role at the same time. Waterproof effect, so that vibration, impact, cable tension, twist and so on are protected.



Applications:

Used for direct transmission of outdoor cable in aerial

Duct and direct buried application
Used for branching connection and protect the joint



Specification:



Product name Horizontal Type Vertical Fiber Optic Splice Box
Protection level IP68
Scope of application 12 core to 144 core
Gross weight 5.7 kg
Main material PC
Scope of use Outdoor Aerial Dome,Buried,pole mount type outdoor
Ambient temperature - 40 °C ~ + 60 °C
Service life ≥20 years
Application scope FTTH FTTB FTTX Network
Atmospheric pressure 70kPa~106kPa
Insulation resistance >2*10MΩ/500V(pc)
Tensile strength >1200N
