288 Cores Horizontal Type 3 Inlets 3 Outlets Outdoor Aerial Dome Duct Mounting Fiber Optical Splice Closure

288 Cores Horizontal Type 3 Inlets 3 Outlets Outdoor Aerial Dome Duct Mounting Fiber Optical Splice Closure

Model Number: FS-J-023
Cable Port: 3 Inlets 3 Outlets
Scope Of Application: 12 Core To 288 Core
Product Size: 560*240*130mm

288 Cores Horizontal Type 3 Inlets 3 Outlets Outdoor Aerial Dome Duct Mounting Fiber Optical Splice Closure

Description:

According to the appearance structure can be divided into Dome type cable joint box and horizontal cable joint box. 288 Cores Horizontal Type 3 Inlets 3 Outlets Outdoor Aerial Dome Duct Mounting Fiber Optical Splice Closure, also known as 288 Cores Horizontal Type 3 Inlets 3 Outlets Outdoor Aerial Dome Duct Mounting Fiber Optical Splice Box, is the place where the end of optical cable is connected. 288 Cores Horizontal Type 3 Inlets 3 Outlets Outdoor Aerial Dome Duct Mounting Fiber Optical Splice Closure are widely apply for the connecting of optical cable.It Suitable for straight-through, diverging and connection of FTTH. FTTB all kinds of optical communication passive network. it is one of the common equipment of user access points, mainly completing the outdoor connection between wiring cable and household cable, and the cassette or simple optical separator can be installed according to the FTTX access needs.

Specification:

Product name	288 cores Horizontal Type Cable Joint Box
Protection level	IP68
Scope of application	12 core to 288 core
Gross weight	5.7 kg
Main material	PC alloy
Scope of use	Outdoor Aerial Dome,Buried,pole mount type outdoor
Ambient temperature	- 40 °C ~ + 60 °C
Service life	≥20 years
Application scope	FTTH FTTB FTTX Network
Atmospheric pressure	70kPa~106kPa
Insulation resistance	>2*10MΩ/500V(pc)
Tensile strength	>1200N
